Lightweight Aluminum Frame
Built with a durable yet lightweight aluminum frame, offering strength and stability while remaining easy to maneuver for caregivers.
In stock
Couldn't load pickup availability

The Hoyer Presence® is expertly engineered to manage nearly any resident-handling task with ease and efficiency. Featuring Smart Monitor™ technology, it tracks lift activity and provides service reminders to promote proper maintenance and long-term reliability.
With a 500 lb. safe working load and an extended lifting range, the Presence is ideal for transferring residents from the floor or to elevated surfaces—making it an excellent choice for both standard and bariatric care. Its spacious design ensures comfort and accessibility for larger individuals.
The lift comes standard with a powered base for smooth positioning and is also available with an optional integrated scale, offering additional functionality for caregivers.
Built with a durable yet lightweight aluminum frame, offering strength and stability while remaining easy to maneuver for caregivers.
Integrated Smart Monitor™ system tracks lift usage and provides service reminders to help extend product life and ensure optimal performance.
Designed for effortless movement initiation, the ergonomic push pad helps caregivers safely and efficiently maneuver the lift in tight spaces.
The swan neck leg design enables closer positioning to the resident, providing enhanced safety and smoother transfers to and from chairs or wheelchairs.
An optional low-leg configuration allows access under low-clearance beds, stretchers, and furniture for greater versatility in care settings.
500 lbs / 227 kg
57.5 in / 1460 mm
55.1 in / 1400 mm
81.3 in / 2065 mm
57.5 in / 1460 mm
16.9 in (min) – 75.2 in (max) / 430 mm – 1910 mm
51.5 in / 1310 mm
Tested to EN ISO 10535 — the international safety and performance standard for patient lifts.
| Specification | Details |
|---|---|
| Safe Working Load | 500 lbs |
| Maximum Overall Length | 57.5″ |
| Minimum Overall Length | 55.1″ |
| Maximum Overall Height | 81.3″ |
| Minimum Overall Height | 57.5″ |
| Spreader Bar Maximum Height | 75.2″ |
| Spreader Bar Minimum Height | 16.9″ |
| Height at Maximum Reach | 51.5″ |
| Reach at Maximum Height | 25.6″ |
| Reach at Minimum Height | 15.7″ |
| Maximum Reach* | 36.6″ |
| Turning Radius | 64.2″ |
| Legs Open – External Width | 45.2″ |
| Legs Open – Internal Width | 40.1″ |
| Legs Closed – External Width | 26.4″ |
| Legs Closed – Internal Width | 21.6″ |
| Overall Height of Legs | 4.7″ |
| Overall Height of Low Legs (Optional) | 2.4″ |
| Ground Clearance | 1.4″ |
| Front Twin Casters | 4″ |
| Rear Braked Casters | 4″ |
| 4-Point Positioning Cradle | |
| Cradle Max Height | 61″ |
| Cradle Min Height (Usable) | 15.4″ |
| Weights | |
| Mast, Base & Boom Assembly | 81.4 lbs (includes 2-point spreader bar) |
| Power Pack | 6.6 lbs |
| Total Weight | 88 lbs |
| Base Assembly (without battery) | 44 lbs |
| Mast & Boom (without battery) | 37.4 lbs |
| 4-Point Position Cradle | 13.2 lbs |
| Electrical Specifications | |
| Battery Type | 24V Rechargeable Sealed Lead Acid |
| Battery Capacity | 3.2 Ah |
| Charger Input | 100–240V AC / 50–60Hz |
| Charger Output | 29.5V DC / Max 19W |
| Charger Protection Class | Class II (EN 60601-1) |
| Lift Power Source | Internal Power Source |
| Shock Protection Rating | Type B (EN 60601-1) |
| Environmental Conditions | |
| Operating Temperature | 41°F – 104°F |
| Relative Humidity (Operating) | 20% – 90% (non-condensing) |
| Storage Temperature | 14°F – 122°F |
| Relative Humidity (Storage) | 20% – 90% (non-condensing) |
| IP Ratings & Duty Cycle | |
| Control Box | IPX4 |
| Actuator | IPX4 |
| Off-Board Charger | IPX5 |
| Battery | IPX5 |
| Handset | IPX4 |
| Actuator Duty Cycle | 10% (2 min ON / 18 min OFF) |
| Charger Time | Approx. 4 hours |
| Acoustics | |
| Sound Power Level | 60 dB(A) |
Download The Hoyer Patient Lift Brochure
Download The Hoyerpro+ ® Adaptive Positioning Cradle Manual
This warranty applies to HoyerPro® Lifts only. It does not cover other models such as HML400, HPL700, HPL700WSC, HPL402, C-HLA, and their variations.
Mechanical & Electrical Components: Covered for two years from the date of delivery under normal use and service.
Aluminum Structural Components & Welds: Covered for the lifetime of the product from the delivery date.*
*Subject to standard warranty exclusions below.
This warranty does not cover:
Damage due to improper environmental conditions
Failure to maintain the product per user/service instructions
Unauthorized modifications, repairs, or alterations
Wear Items (e.g., batteries, casters, hydraulic pumps): Covered for 90 days from date of delivery
Warranty replacement parts: Covered until the expiration of the product’s original warranty period
Return of parts for inspection is required upon request (customer expense). Credit issued upon inspection approval.
Most service issues can be resolved by the facility’s Maintenance Department with guidance from Joerns Healthcare’s Product Service Team.
Parts are available and can be shipped next-day air (shipping charges apply).
If an on-site technician is needed, Joerns Healthcare may dispatch one at its discretion. Only our Product Service Department may authorize service calls.
This warranty is extended to the original purchaser of the equipment.
