Combo-Perior Floor Lift & Transfer System | VOCIC AX36
Key Features & Benefits
- ✓ Weight Capacity: 353 lbs | Flip-Up Armrests
- ✓ Range: 3.5" above the floor to a 19.7" seated height
- ✓ Stable Dual-Motor Lift System | Padded Backrest
- ✓ Powered Forward and Reverse Movement
- ✓ Dimensions: 28.1" x 23.9"
In stock
Couldn't load pickup availability
Speak To An Expert
FREE Shipping
30-Day Return Policy
24/7 Support
FSA/HSA Eligible
Similar Products

The AX36 Combo-Perior Lift & Transfer Chair combines motorized floor-recovery lifting with powered indoor mobility to help caregivers assist individuals with limited mobility following a non-emergency fall. Using a simple handheld controller, the chair raises the user smoothly from just 3.5 inches above the floor to a seated height of 19.7 inches, eliminating the need for caregivers to lift the person manually.
A stable dual lead-screw motor system delivers balanced height adjustment while helping minimize movement and shaking during the lifting process. Once the user is seated securely, rear hub motors provide powered forward and reverse movement at the touch of a button. Releasing the control stops the chair, giving caregivers intuitive control while reducing the physical effort required for short-distance indoor transfers.
Built from durable Q235 carbon steel and AL6063 aluminum alloy, the AX36 supports users weighing up to 353 pounds. A padded leather backrest, integrated safety belt, flip-up armrests, and supportive seating provide greater security and comfort during recovery and movement. Its modern, home-friendly appearance helps the chair blend more naturally into bedrooms, living areas, and residential care environments.
Ideal Applications
✔ Non-emergency fall recovery
✔ Seniors living at home
✔ Individuals with limited mobility
✔ Family and spouse caregivers
✔ Assisted living environments
✔ Rehabilitation and community care
✔ Short-distance indoor transfers
✔ Caregiver injury-risk reduction
-
Motorized Ground-Level Lifting
Raises the user from 3.5 inches above the floor to a 19.7-inch seated height without dangerous manual lifting. -
Stable Dual-Motor Lift System
Dual lead-screw motors provide controlled, balanced lifting with reduced shaking during height adjustment. -
Powered Forward and Reverse Movement
Rear hub motors move the chair in either direction at the push of a button, helping reduce caregiver effort. -
Simple Push-Button Controls
Intuitive controls operate the lift and powered movement functions. Releasing the movement button stops the chair. -
353-Pound Weight Capacity
A reinforced carbon steel and aluminum alloy structure supports a wide range of users. -
Integrated Safety Belt
Helps keep the user securely positioned during lifting and caregiver-assisted movement. -
Flip-Up Armrests
Create additional access for transfers while providing upper-body support when lowered. -
Padded Backrest
A wood-supported backrest with leather upholstery provides stable, comfortable positioning. -
Front Casters with Brakes
Two-inch front casters support maneuverability and can be locked for greater stability during lifting and transfers. -
Compact Indoor Design
The 28.1-by-23.9-inch footprint is designed for maneuvering through appropriate residential and care spaces.


Specifications
| Material | Carbon Steel (Q235) and Aluminum Alloy (AL6063) |
|---|---|
| Padded Backrest Material | Wood Board and Leather |
| Weight Capacity | Up to 353 lbs. (160 kg) |
| Net Weight | 50.3 lbs. (22.8 kg) |
| Seat Width | 15″ (380 mm) |
| Armrest Spacing | 17.3″ (440 mm) |
| Seat Depth | 16.9″ (430 mm) |
| Lifting Range | 3.5″–19.7″ (90–500 mm) |
| Dimensions (L x W x H) | 28.1″ x 23.9″ x 30.9″–48.2″ (715 x 606 x 785–1,225 mm) |
| Maximum Forward/Reverse Speed | 1.1 mph (1.7 km/h) |
| Lifting Speed | 5 mm/s |
| Front Caster Wheels | 2″ with Brakes |
| Rear Drive Wheels | 6.5″ |
| Hub Motor Rated Power | 150 W |
| Battery | 24 V / 2,600 mAh |
Videos
Downloads
FAQs
Frequently Asked Questions
Tap a question below to view the answer.
What is the AX36 Combo-Perior Lift & Transfer Chair?
The AX36 is a powered floor-recovery and indoor transfer chair designed to raise a person from near floor level into a supported seated position. Its powered rear wheels also help caregivers move the seated user forward or backward over suitable indoor surfaces.
Who may benefit from the AX36?
It may benefit seniors, individuals with limited mobility, people recovering from a non-serious fall, and caregivers seeking an alternative to lifting someone manually.
What is the AX36 weight capacity?
The chair supports users weighing up to 353 pounds (160 kg).
How low does the seat go?
The seat lowers to approximately 3.5 inches (90 mm) above the floor.
What is the maximum lifting height?
The seat rises to approximately 19.7 inches (500 mm).
Can the AX36 lift someone directly from the floor?
The chair lowers close to floor level so the user can be positioned on its seat before lifting. Depending on the person’s condition and mobility, caregiver assistance may be required to position them safely.
How is the lifting function operated?
A simple controller operates the motorized lift, allowing the seat to rise or lower in a smooth, controlled manner.
How fast does the chair lift?
The published lifting speed is approximately 5 mm per second.
What helps keep the lift stable?
The AX36 uses a dual lead-screw motor structure designed to provide balanced lifting and minimize shaking during height adjustment.
Does the chair provide powered movement?
Yes. Rear hub motors provide powered forward and reverse movement using push-button controls.
How fast does the chair travel?
The maximum published forward and reverse speed is approximately 1.1 mph (1.7 km/h).
Is the AX36 a replacement for a power wheelchair?
No. It is primarily a floor-recovery and transfer-assistance device for appropriate indoor environments. It should not be used as a substitute for a prescribed power wheelchair or mobility scooter.
Can the user operate the AX36 independently?
Operation should be based on the user’s physical and cognitive abilities and the manufacturer’s instructions. Caregiver supervision or operation may be necessary, particularly during floor recovery and transfers.
Does the chair include a safety belt?
Yes. An integrated safety belt helps stabilize the user during lifting and caregiver-assisted movement.
Do the armrests move?
Yes. The flip-up armrests provide easier access for positioning and transfers. They should be lowered and secured when support is needed.
Do the wheels have brakes?
The AX36 has 2-inch front casters with brakes. Engage the brakes as directed before lifting, lowering, or transferring the user.
What size are the rear wheels?
The powered rear drive wheels measure approximately 6.5 inches.
What are the seat dimensions?
The seat is approximately 15 inches wide and 16.9 inches deep, with 17.3 inches of space between the armrests.
What are the chair’s overall dimensions?
The AX36 measures approximately 28.1 inches long, 23.9 inches wide, and 30.9 to 48.2 inches high, depending on the lift position.
How much does the AX36 weigh?
The chair has a net weight of approximately 50.3 pounds (22.8 kg).
What materials are used in its construction?
The frame combines Q235 carbon steel and AL6063 aluminum alloy. The padded backrest includes a wood support board with leather upholstery.
What type of battery does it use?
The AX36 is powered by a 24V, 2600mAh battery.
What is the motor power?
The rear hub motor has a published rated power of 150 watts.
Can the AX36 be used outdoors?
It is designed primarily for suitable indoor environments. Do not use it on stairs, steep slopes, loose surfaces, wet floors, or uneven terrain unless the manufacturer specifically permits such use.
Can it be used to transport someone in a vehicle?
No. The AX36 is not described as a crash-tested motor-vehicle seat. Transfer the user to an approved vehicle seat and secure the unoccupied chair separately during transportation.
Is the AX36 appropriate for every fall?
No. It is intended only for non-emergency fall recovery when no injury is suspected. Do not lift or move someone who may have sustained a head, neck, back, hip, or other serious injury.
When should emergency services be contacted?
Call emergency medical services if the person is unconscious, confused, experiencing severe pain, bleeding, unable to move normally, or may have sustained an injury. Seek emergency assistance whenever there is uncertainty about moving the individual safely.
What should be checked before each use?
Check the battery level, controller, safety belt, armrests, wheels, brakes, frame, seat, and lifting mechanism. Confirm that the user does not exceed the weight capacity and that the surrounding floor is level and clear.
Is assembly required?
The product is designed for straightforward setup, but installation requirements may vary. Follow the supplied assembly and operating instructions before using the chair.
What safety precautions should caregivers follow?
Assess the user for injury, position them securely, fasten the safety belt, engage the brakes when required, keep hands and clothing away from moving components, and operate the lift only on a stable, level surface. Never exceed the 353-pound capacity.
